Product Description

Main Motor 75KW

Drilling Force 460KN

Pile Depth ≤28M

Total Weight 25000KG

Equipment Specifications
Main motor	75KW
Diameter	Ø1200mm
Drilling motor	18.5KW
Oilpump motor	18.5KW
Drilling force	460KN
Drilling speed	0.05-2.2m/min
Rotating speed (Forward)	5-96RPM
Rotating speed (Reverse)	5-90RPM
Total Weight	25000KG
Pile depth	≤28M
Drill rod specifications	180x180x16mm
Pile diameter	≤1200mm
Core pile section size	500-1200mm
Chain Size	36A
Mast structure height(M)	Type II-30M
Hydraulic walking (Longitudinal step)	1.8M
Hydraulic walking (Horizontal step)	0.6M
Base frame size	8200*2300mm

Frequently Asked Questions

What is the total motor configuration and power of this equipment?

The machine is equipped with a 75KW main motor, an 18.5KW drilling motor, and an 18.5KW oil pump motor to deliver powerful performance during operations.

What are the maximum pile depth and diameter capabilities?

This rig can achieve a maximum pile depth of ≤28 meters and supports a pile diameter of ≤1200mm, making it suitable for a wide range of foundation tasks.

How fast can the drill rotate in forward and reverse modes?

The equipment features variable rotation speeds, with a forward rotating speed range of 5-96 RPM and a reverse rotating speed range of 5-90 RPM.

What is the overall size and weight of this machinery?

The total weight of the equipment is 25,000 KG. It has a base frame size measuring 8200*2300mm and a mast structure height of Type II-30M.

What is the step movement distance of the hydraulic walking system?

The hydraulic walking system permits a longitudinal step distance of 1.8 meters and a horizontal step distance of 0.6 meters for precise positioning.

What are the exact drill rod and core pile section specifications?

The drill rod specifications are 180x180x16mm, and it accommodates core pile section sizes ranging from 500mm to 1200mm.
