The leading hydraulic pile breaker with five patented technologies and adjustable chain, it is the most efficient equipment to break the foundation piles.
1. Environment-friendly
Its full hydraulic drive causes little noises during operation and no influence on the surrounding environments.
2. Low-cost
The operating system is easy and convenient. Fewer operating workers are required to save cost for labor and machines maintenance during construction.
3. Small volume
It's light for convenient transportation.
4. Safety
Contact-free operation is enabled and it can be applied for construction on complex land form.
5. Universal property
It can be driven by diverse power sources and is compatible with excavators or hydraulic system according to the construction sites conditions. It is flexible to connect multiple construction machines with universal and economical performance. The telescopic sling lifting chains meet the requirements of various land forms.
6. Long service life
It is made of military material by first-class suppliers with reliable quality, extending its service life.
Operation Process (Steps 1-4)
1
According to pile diameter, with reference to the construction reference parameters corresponding to the number of modules, directly connect the breakers to the work platform with a quick change connector;
2
The working platform can be excavator, lifting device and hydraulic pump station combination, the lifting device can be truck crane, crawler cranes, etc;
3
Move the pile breaker to the working pile head section;
4
Adjust the pile breaker to the suitable height (please refer to construction parameter list when crushing the pile, otherwise the chain may be broken), and clamp the pile position to be cut;
Reference Parameters
Length of drill rod
Pile Diameter (mm)
Remark
170
300-400
Standard Configuration
206
200-300
Optional Configuration
The hydraulic pile breaker has the following features: easy operation, high efficiency, low cost, less noise, more safety and stability. It imposes no impact force on the parent body of the pile and no influence on the bearing capacity of the pile, and shortens the construction period greatly. It is applicable for pile-group works and is recommended strongly by the construction department and the supervision department.
Operation Process (Steps 5-7)
5
Adjust the excavator's system pressure according to the concrete strength, and pressurize the cylinder until the concrete pile breaks under high pressure;
6
After the pile is crushed, hoist the concrete block;
7
Move the crushed pile to the designated position.
Specification
Model
SPF400B
Range of Pile diameter (mm)
300-400
Maximum Drill rod pressure
325kN
Maximum stroke of hydraulic cylinder
150mm
Maximum pressure of hydraulic cylinder
34.3MPa
Maximum flow of single cylinder
25L/min
Cut the number of pile/8h
160
Height for cutting pile each time
≦300mm
Supporting the digging machine Tonnage(excavator)
≥7t
Work status dimensions
1600X1600X2000mm
Total pile breaker weight
650kgs
Frequently Asked Questions (FAQ)
What makes the hydraulic pile breaker environmentally friendly?
The equipment utilizes a full hydraulic drive system, which generates minimal noise during operation, avoiding disturbance to the surrounding environments.
Which power sources are compatible with this pile breaker?
It features universal compatibility and can be powered by diverse sources, including excavators, crane setups, crawler cranes, or independent hydraulic pump stations.
Does the pile breaker affect the pile's load-bearing capacity?
No. The hydraulic pile breaker applies static pressure, meaning it imposes no impact force on the parent body of the pile and has no negative influence on its bearing capacity.
What is the productivity rate of the SPF400B model?
The SPF400B model can cut and process up to 160 piles within an 8-hour shift, significantly shortening the overall construction period.
What excavator size is required to support the SPF400B pile breaker?
The SPF400B model requires a supporting digging machine or excavator with a tonnage rating of 7 tons (≥7t) or higher.
