| Item |
Unit |
YTQH1000B |
| Compaction capacity |
t.m |
1000(2000) |
| Hammer weight permit |
t.m |
50 |
| Wheel tread |
mm |
7300 |
| Chassis width |
mm |
6860 |
| Track width |
mm |
850 |
| Boom length |
mm |
20-26（29） |
| Working angle |
° |
66-77 |
| Max.lift height |
mm |
27 |
| Working radius |
mm |
7.0-15.4 |
| Max. pull force |
t.m |
25 |
| Lift speed |
m/min |
0-110 |
| Slewing speed |
r/min |
0-1.5 |
| Travel speed |
km/h |
0-1.4 |
| Grade ability |
— |
30% |
| Engine power |
kw |
294 |
| Engine rated revolution |
r/min |
1900 |
| Total weight |
t.m |
118 |
| Counter weight |
t.m |
36 |
| Main body weight |
t.m |
40 |
| Dimension(LxWxH) |
mm |
95830x3400x3400 |
| Ground pressure ratio |
M.pa |
0.085 |
| Rated pull force |
t.m |
13 |
| Lift rope diameter |
mm |
32 |
Key Features & Benefits
Mature platform structure.
Large slewing bearing, large bearing capacity and high reliability.
High-quality hydraulic components.
New heavy-duty main winch.
Efficient: Work efficiency increased by 34%.
Low consumption: Segmented intelligent work, cross power control, fuel consumption reduced by 21.7%.
The pulling force of the hoisting single rope is large.
The operation is light and flexible.
It can work for a long time and with high power.
Frequently Asked Questions
What is the compaction capacity of the YTQH1000B?
The compaction capacity of the YTQH1000B is 1000(2000) t.m.
How fuel-efficient and productive is the YTQH1000B?
Thanks to segmented intelligent work and cross power control, the overall fuel consumption is reduced by 21.7%, while the work efficiency is increased by 34%.
What are the engine specifications for this model?
The YTQH1000B is equipped with an engine featuring 294 kw of power and a rated revolution of 1900 r/min.
What are the dimensions and total weight of the machinery?
The total dimensions (LxWxH) are 95830x3400x3400 mm, and the total operational weight is 118 t.m, with a main body weight of 40 t.m and a counter weight of 36 t.m.
What structural improvements enhance the reliability of the YTQH1000B?
It features a mature platform structure, a large slewing bearing that offers large bearing capacity and high reliability, high-quality hydraulic components, and a new heavy-duty main winch design.
