| Hopper | ||
|---|---|---|
| Diameter (mm) | Height (mm) | Weight (kg) |
| 408 | 950 | 70 |
| 508 | 850 | 75 |
| 658 | 870 | 91 |
| 758 | 970 | 123 |
| 1058 | 1250 | 207 |
| Conduit | |
|---|---|
| Length (mm) | Weight (kg) |
| 1000 | 49 |
| 2000 | 86 |
| 3000 | 123 |
| 4000 | 160 |
| 5000 | 197 |
| 6000 | 234 |
| Hopper 2 | |||
|---|---|---|---|
| D (Diameter) | H (Height) | Weight (KG) | Capacity (m³) |
| 1500 | 1270 | 179 | 1 |
| 1500 | 1670 | 235 | 1.5 |
| 1860 | 1520 | 263 | 2 |
| 2000 | 1350 | 288 | 3 |
| Conduit 2 | |||
|---|---|---|---|
| L1 (mm) | Weight (KG) | L2 (mm) | Weight (KG) |
| 500 | 42 | 3900 | 134 |
| 1000 | 54 | ||
| 1500 | 70 | ||
| 2000 | 85 | ||
| 3000 | 112 | ||
| D (mm) | P (mm) | δ (mm) | L (m) | Weight (Kg) |
|---|---|---|---|---|
| 400 | 340 | 16 | 2 | 283 |
| 3 | 386 | |||
| 4 | 489 | |||
| 5 | 592 | |||
| 6 | 695 | |||
| 500 | 400 | 16 | 2 | 465 |
| 3 | 638 | |||
| 4 | 811 | |||
| 5 | 983 | |||
| 6 | 1156 | |||
| 600 | 500 | 20 | 2 | 526 |
| 3 | 730 | |||
| 4 | 933 | |||
| 5 | 1137 | |||
| 6 | 1340 | |||
| 800 | 500 | 20 | 2 | 671 |
| 3 | 948 | |||
| 4 | 1223 | |||
| 5 | 1499 | |||
| 6 | 1775 | |||
| 1000 | 500 | 20 | 2 | 865 |
| 3 | 1225 | |||
| 4 | 1592 | |||
| 5 | 1961 | |||
| 6 | 2329 |
| φ (Diameter) | P (mm) | δ1 (mm) | δ2 (mm) | Weight (KG) |
|---|---|---|---|---|
| 400 | 340 | 30 | 16 | 254 |
| 500 | 400 | 30 | 16 | 386 |
| 600 | 500 | 40 | 20 | 449 |
| 800 | 500 | 40 | 20 | 603 |
| 1000 | 500 | 40 | 20 | 797 |
Our standard Hoppers are available in diameters ranging from 408mm to 1058mm, with heights between 850mm and 1250mm, and weights ranging from 70kg up to 207kg.
The Hopper 2 models are engineered for larger volumes, offering capacities of 1 m³, 1.5 m³, 2 m³, and 3 m³ matching diameters up to 2000mm.
Standard Conduits scale incrementally by length. A 1000mm length starts at 49kg, and the weight increases proportionally up to 234kg for the 6000mm length model.
We offer thickness ratings (δ) of 16mm for pipe diameters of 400mm and 500mm, and 20mm thickness for larger diameters of 600mm, 800mm, and 1000mm.
For Conduit 2, variables L1 (ranging from 500mm to 3000mm) carry weights from 42kg to 112kg, whereas the standard L2 model features a constant length of 3900mm and weight of 134kg.
